Ebay - Rack PDU 2G, Switched, ZeroU, 20A/208V, 16A/230V, (21) C13 and (3) C19

About Switched Rack PDU:
ftp to PDU and enter "about" at the prompt:
Hardware Factory
Model Number: 		AP8959EU3
Serial Number: 		ZA1330021822
Hardware Revision: 	02
Manufacture Date: 	07/30/2013
MAC Address: 		00 C0 B7 B4 66 04
Management Uptime: 	1 Day 0 Hours 43 Minutes

Network Management Card
Model Number: 		AP9537
Serial Number: 		ZA1330022907
Hardware Revision: 	05
Manufacture Date: 	07/27/2013

Application Module
Name: 			rpdu2g
Version: 		v5.1.6
Date: 			Oct 15 2012
Time: 			10:34:14

Name: 			aos
Version: 		v5.1.9
Date: 			Oct 15 2012
Time: 			09:48:19

APC Boot Monitor
Name: 			bootmon
Version: 		v1.0.2
Date: 			Jan 21 2010
Time: 			13:35:57

APC Product Page:


Product Description

Remote Individual Outlet Control

Remotely manage outlets so users can turn outlets off that are not in use (prevent overloads) or recycle power to locked-up equipment (minimize costly downtime and avoid travel time to equipment).

Power Delays

Allows users to configure the sequence in which power is turned on or off for each outlet. This helps avoid in-rushes at start-up, which can cause overloaded circuits and dropped loads. Sequencing also allows users to predetermine which piece of equipment is turned on first so other equipment dependant on that unit will function properly.

Remote Management Capabilities

Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.

Alarm Thresholds

Define alarm thresholds in order to avoid overloaded circuits. Network and visual alarms inform the user of possible problems. Local Current Monitoring Display. The aggregate current draw per power distribution unit is displayed on the unit via a digital display. The local digital display helps installers avoid overloaded circuits by providing a visible warning when the current draw is close to the maximum amperage draw of the strip.



Rack PDU 2G, Switched, ZeroU, 16A, 230V, (21) C13 & (3) C19, IEC309 Cord
APC Switched Rack PDU , Input: 200V, 208V, 230V ,
Input Connections: IEC 309 16A 2P+E , Cord Length: 9.84 feet ( 3 meters ) ,
Output: 230V , Output Connections: IEC 320 C13,IEC 320 C19

Includes: Installation guide, Locking input power cord, Rack Mounting brackets,
        Safety guide, Sample locking IEC power cord, Serial configuration cable

Output Nominal
Output Voltage 230V
Maximum Total Current Draw per Phase 16A
Output Connections (21) IEC 320 C13 (3) IEC 320 C19
Overload Protection No
Nominal Input Voltage 200V,208V,230V
Input Frequency 50/60 Hz I
Input Connections IEC 309 16A 2P+E
Cord Length: 3 meters
Number of Power Cords: 1
Acceptable Input Voltage: 220-240 VAC
Maximum Line Current per phase 16A
Maximum Input Current per phase 16A
PhysicalNet Weight 5.73 KG
Maximum Height 1791.00 mm
Maximum Width 56.00 mm
Maximum Depth 46.00 mm
Shipping Weight 8.59 KG
Shipping Height 2002.00 mm
Shipping Width 165.00 mm
Shipping Depth 114.00 mm
Color Black
Operating Environment -5 - 45 ?C
Operating Relative Humidity 5 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -25 - 65 ?C
Storage Relative Humidity 5 - 95%
Storage Elevation 0-15000 meters
Regulatory Approvals cUL Listed,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,FCC Part 15 Class A,ICES-003,PSE,UL Listed,VCCI Class A,VDE
Standard Warranty 2 years repair or replace
Environmental Compliance RoHS,REACH: Contains No SVHCs,Contains Lithium Battery


Firmware Updates

Installation manual for Metered Rack Power Distribution Unit:

Software and Firmware selection Page:

Network Management Card v6.6.4 RPDU 2G Firmware Executable:


Programming Interface

User Guide Rack Power Distribution Unit Switched AP89XX (990-5569H-001)
Published October 2018:
Note that this document has disapeared from online at apc.com This is a local to this site copy.
User-Guide-MLAN-9F8QVU_R8_EN.pdf (Local)

This is a very similar document that appeaer to have replaced the User Guide above. However it no longer directly references the 89XX models thta I am working with.
User Guide Configurable Rack Power Distribution Unit Metered-by-Outlet with Switching (990-91135A-001)
Publication Date: October 2018:

Possible programming application:


Drawings - Switched Rack PDU 2G




Security Handbook Network-Enabled Devices, AOS v6.4.x and v6.5.x (990-4910B-001)
Published November, 2017:


APC MIB's Downloads

APC MIB's can be downloaded here:

APC FAQ on PowerNet:

Glenn Lyons VK4PK
Ver:gnl20190226 - pre published v0.9
